KAWASAKI BEAM TROLLEY TBC

Brand customization: OEM, appearance color, logo, etc.
Material customization: chain T80 T100, copper alloy, stainless steel, aluminum alloy
Function customization: 360° operation, stage upside down hoist, load limiting function, with electronic scale, riot-proof, rust-proof
Chain customization: polished and oiled, electro-galvanized, nickel-plated, blackened, Dacromet
Packaging customization: Customized according to customer needs such as: yellow board cartons, color boxes, wooden boxes
Customized minimum order quantity: 100

KAWASAKI BEAM TROLLEY TBC

Brand customization: OEM, appearance color, logo, etc.
Material customization: chain T80 T100, copper alloy, stainless steel, aluminum alloy
Function customization: 360° operation, stage upside down hoist, load limiting function, with electronic scale, riot-proof, rust-proof
Chain customization: polished and oiled, electro-galvanized, nickel-plated, blackened, Dacromet
Packaging customization: Customized according to customer needs such as: yellow board cartons, color boxes, wooden boxes
Customized minimum order quantity: 100

Product details

Product details

• Available in capacities of 2 thru 10 metric tons
• Welded alloy steel body for strength and smaller size. Forgrd alloy components, where required
• Individually proof tested to 2 times the working load limit with cerrification
• Each product is individually serialized, with the serial number and proof load test date stamped on body Serial number is included on the test certificate with maintenance and warranty logbook
• Maintenance replacement parts are available
• Maintenance by a ISO9001 facility
• All sizes are RFID EQUIPPED, OPTIONAL EXTRA
• Can be supplied with shackle
• Special design thin flattened, reinforced jaws

Model 1T 2T 3T 5T 10T
Capacity(kg) 1000 2000 3000 5000 10000
Running test load(kN) 14.71 29.42 44.13 61.29 122.58
Adjustable Beam Width(MM) 75 ~ 230 75 ~ 230 80 ~ 320 90 ~ 320 90-320
Dimensions(mm) Amax 278 278 356 356 356
Bmax 380 380 500 500 500
Bmin 183 183 220 220 250
C 64 76 100 112 120
D 4 6 8 10 12
E 217 217 277 277 285
Fmax 150 150 220 220 230
Fmin 90 90 145 145 160
G 26 26 50 47 52
H 19 21 23 29 39
Weight(kg) 3.5 4.5 9.5 11 16
