| Lifting capacity t | 2 | 3 | 5 | 10 |
| Lifting height m | 6-12 | 6-12 | 6-12 | 6-12 |
| Parallel straight rope like manner | 1/2 2/4 |
1/2 2/4 |
1/2 2/4 |
1/2 2/4 |
| Lifting speed m/min | 8(0.8/8) | 8(0.8/8) | 8(0.8/8) | 7(0.7/7) |
| Lifting power kw | 3.0 | 4.5 | 7.5 | 13 |
| Running speed m/min | 0-20 0-30 |
0-20 0-30 |
0-20 0-30 |
0-20 0-30 |
| Operating power kw | 0.4*2 | 0.4*2 | 0.8*2 | 0.8*2 |
| A wire rope | IWR | IWR | IWR | IWR |
| Degree of protection | IP44/54/55 | IP44/54/55 | IP44/54/55 | IP44/54/55 |
| Insulation class | F | F | F | F |
| Control mode | remote/Fully automatic | remote/Fully automatic | remote/Fully automatic | remote/Fully automatic |
| Working level | M3/M4 | M3/M4 | M3/M4 | M3/M4 |
| Power supply | 3P 380V 50Hz | 3P 380V 50Hz | 3P 380V 50Hz | 3P 380V 50Hz |
| Remarks | bottle hoist can have special anti-corrosion / acid base resistance efficacy and increased anticollision / splitter function | |||
