1.High integrity and reliability.
2.Excellent dynamic weighing ability ,does not subject to the influence of shaking.
3.Uniquely intelligent charging protection function preventing from discharging and overcharging ,making the lifetime of the battery much longer.
4.Optional remote controller for convenient operation.
5. Automatic shutoff.
6.High-luminance,low-luminance and auto adjusting (needs setting).
7.Electricity consumption saving design making the electricity consumption of the circuit board much lower.
8. Accumulation, auto accumulation, taring ,long-distance taring,overload alarm and convenient operation,etc.
| Weighing accuracy | Comply with OIML |
| Operation time (with fully charged battery) |
60 hours |
| Safe over-load | 150%F. S. |
| Damaging over-load | 300%F. S. |
| Working temperature range | -10~50℃ |
| Operation humidity | <95%R. H. |
| Dimension of display | 5 digits 30mm(1.2″)LED |
| Stability time of reading | <5.0S |
| Controlling distance | 10-15m |
| Dimension of C5 and C7 series(mm) | Weight (kg) | ||||||
| Capacity(t) | Division(kg) | Length | Ring radian | Ring width | Lifting hook | C5 | C7 |
| 1 | 1 | 505 | 95 | 58 | 35 | 11.5 | 11.8 |
| 2 | 1 | 505 | 95 | 58 | 35 | 11.5 | 11.8 |
| 3 | 1 | 505 | 95 | 58 | 35 | 11.5 | 11.8 |
| 5 | 2 | 610 | 120 | 80 | 45 | 16.4 | 16.7 |
| 10 | 5 | 650 | 125 | 90 | 45 | 21 | 21.3 |
| 15 | 5 | 940 | 135 | 98 | 55 | 45.5 | 45.8 |
| 20 | 10 | 1100 | 235 | 127 | 70 | 73.5 | 73.8 |
| 30 | 10 | 1290 | 335 | 145 | 90 | 98 | 98.5 |
