It supports a 5000kg load capacity, fully meeting heavy material handling needs in warehouses, manufacturing workshops, and logistics handling scenarios.
With a net weight of only 120kg and a compact turning radius (1344/1414mm), plus moderate overall dimensions (length 1550/1620mm, width 550/685mm), it can operate flexibly in relatively narrow workspaces.
It offers a 195mm lifting height and 85mm lowered height, adapting to flexible stacking and goods retrieval; the 1252mm tiller height ensures comfortable operation during long-term use.
Equipped with a 20050mm steer wheel and 8060mm load wheel, paired with a stable wheelbase (1208/1278mm) and tread width (390/525mm), it maintains reliable stability when bearing heavy loads.
It supports a 5000kg load capacity, fully meeting heavy material handling needs in warehouses, manufacturing workshops, and logistics handling scenarios.
With a net weight of only 120kg and a compact turning radius (1344/1414mm), plus moderate overall dimensions (length 1550/1620mm, width 550/685mm), it can operate flexibly in relatively narrow workspaces.
It offers a 195mm lifting height and 85mm lowered height, adapting to flexible stacking and goods retrieval; the 1252mm tiller height ensures comfortable operation during long-term use.
Equipped with a 20050mm steer wheel and 8060mm load wheel, paired with a stable wheelbase (1208/1278mm) and tread width (390/525mm), it maintains reliable stability when bearing heavy loads.
| Identfication | 1.1 | Manufacturer | Machinery | |||
| 1.2 | Model | QBL5 | ||||
| 1.3 | Drive | Manual | ||||
| 1.5 | Load capacity | 0 kg | 5000 | |||
| 1.6 | Load centre distance | c mm | 475 | 510 | ||
| 1.9 | Wheelbase | L0 mm | 1208 | 1278 | ||
| Weights | 2.1 | Net weight | kg | 120 | ||
| Wheels/Frame | 3.2 | Steer wheel | mm | ø200*50 | ||
| 3.3 | Load wheel | mm | ø80*60 | |||
| 3.5 | Wheels, number steer/load | 2/4 | ||||
| 3.6 | Tread width, steer | L1 mm | 122 | |||
| 3.7 | Tread width, load | L12 mm | 390 | 525 | ||
| Basic dimensions | 4.4 | Lift | h mm | 110 | ||
| 4.9 | Height of tiller in drive position | h14 | mm | 1252 | ||
| 4.14 | Height raised | h3 | mm | 195 | ||
| 4.15 | Height lowered | h13 | mm | 85 | ||
| 4.19 | Overall length | L3 | mm | 1550 | 1620 | |
| 4.21 | Width across forks | b5 | mm | 550 | 685 | |
| 4.22 | Fork dimensions | s/e/l | mm | 55/160/1150 | 55/160/1220 | |
| 4.35 | Turning radius | wa | mm | 1344 | 1414 | |
