| lifting capacity t | 3 | 5 | 10 |
| Lifting height m | 6-12 | 6-12 | 6-12 |
| Parallel straight line winding method | 2/4 | 2/4 | 2/4 |
| Lifting speed m/min | 1-10 | 1-10 | 0.8-8 |
| Lifting power kw | 6.1 | 9.5 | 16 |
| Running speed m/min | 0-20 | 0-20 | 0-20 |
| Operating power kw | 0.37*2 | 0.37*2 | 075*2 |
| wire rope | IWR | IWR | IWR |
| Protection level | IP54/55 | IP54/55 | IP54/55 |
| Insulation class | F Level | F Level | F Level |
| Operation mode | remote control/Fully automatic | remote control/Fully automatic | remote control/Fully automatic |
| Work level | M5 | M5 | M5 |
| Power | Full frequency conversion 3P 380V 50HZ | Full frequency conversion 3P 380V 50HZ | Full frequency conversion 3P 380V 50HZ |
| Remarks | Hoist can have special anti-corrosion/Acid and alkali resistance performance and increase bumper/Split/Incremental and absolute value encoders. | ||
