KAWASAKI PNEUMATIC BAL ANCE CRANE HQ

Precision cast alloy sprocket
Integrated precision casting processing and high precision chain matching
Chain wheel carburizing treatment for wear resistance and internal toughness
Motor Rotor
The surface coating of the motor rotor has excellent corrosion resistance
The rotor adopts an eight blade structure with high torque and high speed
The blades are made of graphite, with small deformation and super strong wear resistance
High Precision Bearing
High precision bearings
Achieve greater carrying capacity
Aluminum Alloy Housing
High strength integrated alloy shell
Higher precision
Stronger tensile and torsional strength
High precision precision grinding gear
The planetary reduction structure has high transmission efficiency
Precision grinding of gears with low noise and high precision
Gear surface carburizing treatment has high wear resistance
Brake
High strength and high wear resistance taper brake
Instantly brake upon gas interruption secondary spline type safety anti slip structure
Chain
The safety factor of high-strength carburizing chain reaches more than four times
The carburized surface has excellent wear resistance and impact resistance
Control Handle
Integrated alloy control handle
The emergency stop button instantly shuts off in case of an emergency
There are multiple models including two digit four digit, and six digit controls
Lifting Hook
Forged alloy steel hook
Ensure a safety factor of 6 times high strength and toughness

Mold	Unit	HQ0.25-1		HQ0.5-2		HQ1-1		HQ1-2		HQ2-2		HQ3-1		HQ3-2		HQ5-2
Pressure	Mpa	0.4	0.6	0.4	0.6	0.4	0.6	0.4	0.6	0.4	0.6	0.4	0.6	0.4	0.6	0.4	1.6
Load	(Tons)	0.16	0.25	0.35	0.5	0.65	1	0.7	1	1.5	2	3		3		5
Number of chains	Pieces	1		1		1		2		2		1		2		2
Motor output	(KW)	0.6	1	0.6	1	0.6	1	0.6	1	0.6	1	1.8	3.5	1.5	2	1.5	2
Lifting height	(M)	The standard height is 3 m
Full load lifting speed	(m/min)	18	20	10	11	5	5.5	3	3.6	2.5	2.7	2.5	5	2	3	1.5	1.8
Lifting speed without load	(m³/min)	37	42	16	19	10	11	6	7	5	5.5	6	10	4.2	5	1.2	2.8
Lowering speed at full load	(m³/min)	38	38	17	17	10	10	8	8	7	7	7.5	10.5	5.5	6	2.5	3.2
Air consumption of pneumatic hoist at full load-lifting	(m³/min)	0.7	1.2	0.7	1.2	0.7	1.2	0.7	1.2	0.7	1.2	2	4	1.5	2.6	1.5	2.6
Full load air consumption-descending	(m³/min)	0.8	1.5	0.8	1.5	0.8	1.5	0.8	1.5	0.8	1.5	3.5	5.5	2.2	3.6	2.2	3.6
Chain size	mm	7*21		7*21		7*21		7*21		9*27		13*36		9*27		11.3*31
Chain weight	kg/m	1		1		1		1		1.8		3.8		1.8		1.3
Standard weight	(kg)	26		26		38		32		38		86		68		79
(3 meters lifting height)	(kg)	The standard height is 3 m
Controller air hose length	(m)	74	78	74	78	74	78	74	78	74	78	74	78	74	78	74	78
Full Load Noise-Lift	(dB)	G3/4		G3/4		G3/4		G3/4		G3/4		G3/4		G3/4		G3/4
Air hose connector	(in)	14		14		14		14		14		19		19		19

Configuration anti-overload protection 0.6Mpa

Mechanical fatigue class HQ0.25 M5(2m),

The walking speed of the small car is all at 0.6Mpa pressure parameter
