KAWASAKI PNEUMATIC BALANCE CRANE HQ5

Advantages of Pneumatic Hoists

High Safety: Compressed-air drive ensures spark-free operation, suitable for explosive environments, complementing solutions from electric hoist manufacturers and industrial crane manufacturers.
Air Cut-Off Protection: Automatic stop when air supply is interrupted, preventing load drop, meeting standards of hoist manufacturers and suppliers.
Overload Protection: Prevents lifting beyond rated capacity, aligning with practices of chain hoist manufacturers and crane hoist manufacturers.
Stepless Speed Control: Precise lifting and positioning for Heavy lifting solutions and material lift manufacturers.
High Efficiency: Faster lifting speed and stable performance compared with traditional electric chain hoist systems.
Compact and Lightweight: Easy installation and handling, suitable for warehouse overhead crane and machine shop cranes.
Low Maintenance: Durable structure with reduced downtime, supporting long-term use by hoist suppliers and Heavy lifting hoist suppliers.

Chat Now

Product details

Precision cast alloy sprocket
Integrated precision casting processing and high precision chain matching
Chain wheel carburizing treatment for wear resistance and internal toughness
Motor Rotor
The surface coating of the motor rotor has excellent corrosion resistance
The rotor adopts an eight blade structure with high torque and high speed
The blades are made of graphite, with small deformation and super strong wear resistance
High Precision Bearing
High precision bearings
Achieve greater carrying capacity
Aluminum Alloy Housing
High strength integrated alloy shell
Higher precision
Stronger tensile and torsional strength
High precision precision grinding gear
The planetary reduction structure has high transmission efficiency
Precision grinding of gears with low noise and high precision
Gear surface carburizing treatment has high wear resistance
Brake
High strength and high wear resistance taper brake
Instantly brake upon gas interruption secondary spline type safety anti slip structure
Chain
The safety factor of high-strength carburizing chain reaches more than four times
The carburized surface has excellent wear resistance and impact resistance
Control Handle
Integrated alloy control handle
The emergency stop button instantly shuts off in case of an emergency
There are multiple models including two digit four digit, and six digit controls
Lifting Hook
Forged alloy steel hook
Ensure a safety factor of 6 times high strength and toughness
Leading Hoist & Crane Manufacturer & Supplier | 30+ Years Expertise As a leading hoist manufacturer and supplier with over 30 years of expertise, we provide comprehensive heavy lifting solutions. Our Kawasaki-branded products include electric chain hoists, wire rope hoists, manual hoists, and hand winches, serving as reliable electric hoist suppliers and chain hoist suppliers for mining, construction, and warehouse applications. We also supply industrial lifting clamps and are recognized among top crane manufacturers, offering overhead cranes, warehouse cranes, and port cranes. Committed to quality and innovation, we are your trusted partner for all industrial lifting needs. ISO9001 & CE certified.

Mold	Unit	HQ0.25-1		HQ0.5-2		HQ1-1		HQ1-2		HQ2-2		HQ3-1		HQ3-2		HQ5-2
Pressure	Mpa	0.4	0.6	0.4	0.6	0.4	0.6	0.4	0.6	0.4	0.6	0.4	0.6	0.4	0.6	0.4	1.6
Load	(Tons)	0.16	0.25	0.35	0.5	0.65	1	0.7	1	1.5	2	3		3		5
Number of chains	Pieces	1		1		1		2		2		1		2		2
Motor output	(KW)	0.6	1	0.6	1	0.6	1	0.6	1	0.6	1	1.8	3.5	1.5	2	1.5	2
Lifting height	(M)	The standard height is 3 m
Full load lifting speed	(m/min)	18	20	10	11	5	5.5	3	3.6	2.5	2.7	2.5	5	2	3	1.5	1.8
Lifting speed without load	(m³/min)	37	42	16	19	10	11	6	7	5	5.5	6	10	4.2	5	1.2	2.8
Lowering speed at full load	(m³/min)	38	38	17	17	10	10	8	8	7	7	7.5	10.5	5.5	6	2.5	3.2
Air consumption of pneumatic hoist at full load-lifting	(m³/min)	0.7	1.2	0.7	1.2	0.7	1.2	0.7	1.2	0.7	1.2	2	4	1.5	2.6	1.5	2.6
Full load air consumption-descending	(m³/min)	0.8	1.5	0.8	1.5	0.8	1.5	0.8	1.5	0.8	1.5	3.5	5.5	2.2	3.6	2.2	3.6
Chain size	mm	7*21		7*21		7*21		7*21		9*27		13*36		9*27		11.3*31
Chain weight	kg/m	1		1		1		1		1.8		3.8		1.8		1.3
Standard weight	(kg)	26		26		38		32		38		86		68		79
(3 meters lifting height)	(kg)	The standard height is 3 m
Controller air hose length	(m)	74	78	74	78	74	78	74	78	74	78	74	78	74	78	74	78
Full Load Noise-Lift	(dB)	G3/4		G3/4		G3/4		G3/4		G3/4		G3/4		G3/4		G3/4
Air hose connector	(in)	14		14		14		14		14		19		19		19

Configuration anti-overload protection 0.6Mpa

Mechanical fatigue class HQ0.25 M5(2m),

Traveling trolley	Mold	Unit	HQ0.25-1	HQ0.5-2	HQ1-1	HQ1-2	HQ2-2	HQ3-1	HQ3-2	HQ5-2
	Motor power	kw	0.25	0.25	0.25	0.25	0.25	0.25	0.25	0.25
	Running speed	m/min	13-18	13-16	13-18	12-15	12-15	13	13	12
	Motor air consumption	m³/min	0.45	0.45	0.45	0.45	0.45	0.25	0.25	0.25
	Pneumatic tube connector	in	G1/2	G1/2	G1/2	G1/2	G1/2	G3/4	G1/2	G1/2
	Air tube size (inner diameter)	mm	14	14	14	14	14	13	13	13
	Weight (Trolley)	kg	40	40	40	40	49	49	49	55

The walking speed of the small car is all at 0.6Mpa pressure parameter

Mold	Unit	HQ0.25-1	HQ0.5-2	HQ1-1	HQ1-2	HQ2-2	HQ3-1	HQ3-2	HQ5-2
A	mm	690	690	690	585	585	905	690	685
Al	mm	608	608	608	556	556	885	608	625
B	mm	340	340	436	365	365	539	436	450
C	mm	151	151	202	146	146	246.5	202	220
D	mm	164	164	176	185	185	220	176	260
E	mm	96	96	100	140	140	146	100	170
F	mm	50	50	150	385	385	158	150	158
J	mm	50	50	90	65	65	120	90	120
K	mm	23	23	26.5	26	26	38	26.5	38
H1 Minimum clearance	mm	450	450	520	500	500	807	544	630
H1 Minimum clearance	mm	450	450	520	500	500	807	544	630
H3	mm	430	430	597	528	528	768	597	610
Фa	mm	21	28	53	48	48	69	53	69
Фb	mm	21	28	53	48	48	69	53	69
Фc	mm	25	25	28	28	28	33	28	33
