1,High efficiency and make the most of space.
2,Accurate orientation,highly-efficient operation,improved logistics efficiency.
3,Safe and reliable,monitored operation,easy maintenance.
4,Modular design,low maintenance cost,perfect spare parts and components services.
Lifting capacity t | 0.5 | 1 | 2 | 3 | 5 | 10 | 16 |
Lifting height m | 6-18 | 6-30 | 6-30 | 6-30 | 6-30 | 6-30 | 9-24 |
Rope winding mode | 1/2 | 1/2 | 1/2 | 1/2 | 1/2 | 2/4 | 1/4 |
Lifting speed m/min | 8(0.8/8) | 8(0.8/8) | 8(0.8/8) | 8(0.8/8) | 8(0.8/8) | 7(0.7/7) | 3.5(0.35/3.5) |
Lifting power kw | 0.8 | 1.5 | 3.0 | 4.5 | 7.5 | 13 | 13 |
Running speed m/min | 20 | 20 | 20 | 20 | 20 | 20 | 20 |
Operating power kw | 0.2 | 0.2 | 0.4 | 0.4 | 0.8 | 0.8*2 | 0.8*2 |
Control mode | handle / remote control | handle / remote control | handle / remote control | handle / remote control | handle / remote control | handle / remote control | handle / remote control |
Working level | M3/M4 | M3/M4 | M3/M4 | M3/M4 | M3/M4 | M3/M4 | M3/M4 |
Power supply | 3P 380V 50Hz | 3P 380V 50Hz | 3P 380V 50Hz | 3P 380V 50Hz | 3P 380V 50Hz | 3P 380V 50Hz | 3P 380V 50Hz |
