1. It can be operated using a household power supply.
2. Lightweight and small box design with ease of movement
3. When the rope contacts the limit arm, it will automatically stop lifting
4. 360 degree universal connection hook pad with safety hook lock.
When the rope rotates in reverse, the induction arm brakes the motor.
6. Equipped with lightweight equal core sockets.
7. The winch with built-in safety facilities can be automatically controlled for lifting, and can be used in warehouses, docks, construction sites, and light industrial manufacturing fields. The load activity time is set for static and dynamic sharing.
| Lifting capacity t | 2 | 3 | 5 | 10 | 16 |
| Lifting height m | 30-100 | 30-100 | 30-100 | 30-150 | 24-150 |
| Pulley magnification | 1/2 1/1 |
1/2 1/1 |
1/2 1/1 |
2/4 1/2 1/1 |
1/4 2/4 |
| Lifting speed m/min | 8 16 |
8 16 |
8 16 |
7 7 14 |
3.5 7 |
| Lifting power kw | 3.0 3.0*2 |
4.5 4.5*2 |
7.5 7.5*2 |
13 13 13*2 |
13 18.5*2 |
| Running speed m/min | 20 | 20 | 20 | 20 | 20 |
| Operating power kw | 0.4 0.4*2 |
0.4 0.4*2 |
0.8 0.8*2 |
0.8*2 0.8*2 1.5*2 |
0.8*2 1.5*2 |
| Control mode | remote control | remote control | remote control | remote control | remote control |
| Working level | M3/M4 | M3/M4 | M3/M4 | M3/M4 | M3/M4 |
| Wire rope end fixation method | Rotating rope wedges | Rotating rope wedges | Rotating rope wedges | Rotating rope wedges | Rotating rope wedges |
| Power supply | 3P 380V 50Hz | 3P 380V 50Hz | 3P 380V 50Hz | 3P 380V 50Hz | 3P 380V 50Hz |
